Milestone MP-DA4UHD-H2 4K UHD HDMI Distribution Amplifier – Full Product Details
The Milestone MP-DA4UHD-H2 4K UHD HDMI Distribution Amplifier is a professional AV solution designed to distribute a single HDMI source to four HDMI displays simultaneously. Supporting HDMI 2.0 and resolutions up to 4K@60Hz 4:4:4, it is suitable for conference rooms, classrooms, digital signage, presentation systems and other professional AV installations.
With 18Gbps bandwidth, HDCP compatibility, EDID management and automatic video downscaling, the MP-DA4UHD-H2 helps deliver reliable video distribution across displays with different resolution capabilities. Its compact design and Micro-USB firmware upgrade support make it a practical choice for integrated AV environments.
Key Features of Milestone MP-DA4UHD-H2
- 1×4 HDMI Distribution: Distributes one HDMI input to four HDMI output displays.
- 4K UHD Resolution: Supports video resolutions up to 4K@60Hz 4:4:4 at 8-bit.
- HDMI 2.0 Support: Designed for high-resolution video distribution in professional AV systems.
- 18Gbps Bandwidth: Supports high-bandwidth HDMI video signals.
- Video Downscaling: Can automatically downscale a 4K input to 1080p for compatibility with Full HD displays.
- EDID Management: Offers selectable built-in EDID settings to help match the source and connected displays.
- HDCP Compatibility: Supports HDCP 2.2 and HDCP 1.4-compliant signals.
- CEC Pass-Through: Supports CEC signal pass-through for compatible devices.
- Signal Equalization: Built-in equalization helps compensate for HDMI signal attenuation.
- Status Indicators: LED indicators help identify the unit’s operating status.
- Firmware Upgrade: Supports firmware upgrades through its Micro-USB port.
Technical Specifications
| Brand | Milestone |
| Model | MP-DA4UHD-H2 |
| Product Type | 4K UHD HDMI Distribution Amplifier / 1×4 HDMI Splitter |
| HDMI Input | 1 × Type-A female HDMI |
| HDMI Outputs | 4 × Type-A female HDMI |
| Maximum Resolution | Up to 4K@60Hz 4:4:4, 8-bit |
| HDMI Standard | HDMI 2.0 |
| Bandwidth | 18Gbps |
| HDCP Support | HDCP 2.2 and 1.4 compliant |
| Downscaling | 4K input can be downscaled to 1080p for compatible displays |
| EDID Management | Selectable built-in EDID settings |
| CEC | Pass-through supported |
| Control / Upgrade | 4-pin EDID DIP switch and Micro-USB firmware port |
| Power Supply | 5V DC, 1A |
| Maximum Power Consumption | 2.5W |
| Dimensions (W × H × D) | 142 × 17.6 × 70.4 mm |
| Net Weight | Approximately 260g |
Applications of Milestone MP-DA4UHD-H2
- Corporate conference and meeting rooms
- Professional audio-video installations
- Digital signage and commercial displays
- Classrooms, training rooms and lecture halls
- Presentation systems and auditoriums
- Control rooms and multi-display environments
- Retail, hospitality and public information displays
Compatibility and Installation
The Milestone MP-DA4UHD-H2 connects an HDMI source, such as a computer, media player or presentation system, to as many as four HDMI displays. For reliable operation, use suitable HDMI cables and ensure that the source, displays and content support the intended resolution and HDCP requirements. EDID settings and downscaling can help when connecting displays with different resolution capabilities.
This unit distributes one source to multiple displays; it is not an HDMI matrix switcher and does not independently select different sources for each output.
Why Choose the Milestone MP-DA4UHD-H2?
The Milestone MP-DA4UHD-H2 combines 4K@60Hz video support, four HDMI outputs, EDID management, HDCP compatibility and downscaling in a compact distribution solution. It is designed for professional AV users who need to share the same HDMI source across multiple displays while accommodating compatible 4K and 1080p screens.
Conclusion
The Milestone MP-DA4UHD-H2 4K UHD HDMI Distribution Amplifier is a suitable option for professional AV systems that require one-to-four HDMI video distribution. With HDMI 2.0 support, 18Gbps bandwidth, 4K@60Hz 4:4:4 capability and useful EDID and downscaling features, it supports a range of commercial, educational and corporate display applications.
