ViewSonic LS610WHE WXGA LED Projector – Full Product Details
The ViewSonic LS610WHE is a high-brightness, lamp-free WXGA LED projector designed for classrooms, offices, meeting rooms and professional business presentations. With 4,500 ANSI Lumens brightness, native 1280 x 800 WXGA resolution and a 3,000,000:1 contrast ratio, it delivers bright, detailed and vibrant images in a wide range of presentation environments.
Powered by ViewSonic’s 3rd generation LED technology, the LS610WHE provides up to 60,000 hours of light-source life without mercury-based lamp replacement. Its 1.2x optical zoom, horizontal and vertical ±40° keystone correction, 4-corner adjustment and 360° projection provide flexible installation, while LAN control supports centralized management in professional environments.
Product Specifications
| ViewSonic LS610WHE Specifications | |
|---|---|
| Model | LS610WHE |
| Projection System | 0.65-inch WXGA |
| Native Resolution | 1280 x 800 WXGA |
| Aspect Ratio | 16:10 |
| Brightness | 4500 ANSI Lumens |
| Contrast Ratio | 3,000,000:1 |
| Display Colors | 1.07 Billion Colors |
| Light Source Type | LED |
| Light Source Life | 60,000 Hours |
| Lens | F=1.6–1.75, f=19.16–23.02mm |
| Projection Offset | 79% ±9% |
| Throw Ratio | 1.37–1.64 |
| Optical Zoom | 1.2x |
| Digital Zoom | 0.8x–2.0x |
| Projection Size | 30–300 inches |
| Throw Distance | 0.88–10.59m; 100-inch screen at 2.95m |
| Keystone Correction | Horizontal ±40° / Vertical ±40° |
| 4-Corner Adjustment | Supported |
| Projection | 360° Tilt-Angle Projection |
| Resolution Support | VGA 640×480 to Full HD 1920×1080 |
| HDTV Compatibility | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
| HDMI | 2 x HDMI 1.4, HDCP 1.4 |
| Audio Input | 1 x 3.5mm Audio In |
| Audio Output | 1 x 3.5mm Audio Out |
| USB Type-A | 1 x 5V/1.5A Power / Service |
| Speaker | 10W |
| Control | RS232, RJ45 LAN Control |
| Input Lag | 16ms |
| Noise Level | 34dB Normal / 27dB Eco |
| Power Consumption | 310W Normal / Less than 0.5W Standby |
| Power Supply | 100–240V ±10%, 50/60Hz |
| Operating Temperature | 0–40°C |
| Dimensions | 386 x 276 x 116mm |
| Net Weight | 5.0kg |
| Operating Capability | 24/7 Operation |
| Optical Engine Protection | Sealed Optical Engine with IP5X |
About This Projector
- High Brightness: 4500 ANSI Lumens provides bright and visible presentations in classrooms, offices and business environments.
- WXGA Resolution: Native 1280 x 800 resolution with a 16:10 format is suitable for presentations, documents and educational content.
- Maintenance-Free LED: The 60,000-hour LED light source eliminates frequent lamp replacement.
- Wide Color Gamut: LED technology delivers vivid colors and detailed presentation visuals.
- Flexible Installation: H/V keystone, 4-corner adjustment and 360° projection support different installation requirements.
- Centralized Control: RJ45 LAN control supports professional projector management and compatible control platforms.
Key Features of ViewSonic LS610WHE
- 4500 ANSI Lumens high brightness
- 1280 x 800 native WXGA resolution
- 0.65-inch WXGA projection system
- 3,000,000:1 contrast ratio
- 1.07 billion display colors
- 3rd generation LED technology
- 60,000-hour LED light source life
- 1.2x optical zoom
- 0.8x–2.0x digital zoom
- 30–300-inch projection size
- Horizontal and vertical ±40° keystone correction
- 4-corner adjustment
- 360° tilt-angle projection
- Dual HDMI 1.4 connectivity
- USB Type-A 5V/1.5A power output
- 10W built-in speaker
- RJ45 LAN and RS232 control
- 24/7 operation capability
- IP5X sealed optical engine
- Instant power on/off
Performance & Productivity
The ViewSonic LS610WHE combines 4500 ANSI Lumens brightness with WXGA resolution to provide clear and vibrant presentations, spreadsheets, documents, charts and educational content. Its high 3,000,000:1 contrast ratio and wide color gamut help maintain detailed visuals in both dim and brighter environments.
The lamp-free LED design provides up to 60,000 hours of light-source life, reducing maintenance requirements associated with traditional lamp-based projectors. Dual HDMI inputs, USB Type-A power, LAN control and RS232 provide flexible connectivity for professional presentation installations.
Best Suitable For
- Classrooms and educational institutions
- Corporate offices and meeting rooms
- Business presentations
- Training rooms and seminar halls
- Conference rooms
- Professional presentation environments
- 24/7 presentation and display applications
- Installations requiring low-maintenance projection
Why Choose ViewSonic LS610WHE?
- High Brightness: 4500 ANSI Lumens delivers clear images in bright presentation environments.
- Long LED Life: 60,000-hour light-source life provides a maintenance-free alternative to lamp-based projectors.
- Flexible Installation: H/V keystone, 4-corner adjustment and 360° projection support versatile setups.
- Professional Control: RJ45 LAN and RS232 enable convenient projector management.
- Large Display: Supports projection sizes up to 300 inches.
- 24/7 Operation: Designed for continuous-use environments such as classrooms and business installations.
- Dust Protection: IP5X sealed optical engine helps protect internal optical components from dust.
- Instant Operation: Instant power on/off helps reduce waiting time before and after presentations.
ViewSonic LS610WHE – Professional WXGA LED Business & Education Projector
The ViewSonic LS610WHE is a high-brightness, maintenance-free WXGA LED projector designed for classrooms, offices and professional business presentations. With 4500 ANSI Lumens, 1280 x 800 resolution, 60,000-hour LED life, 1.2x optical zoom, H/V keystone correction, 4-corner adjustment, 360° projection and LAN control, it provides a reliable and flexible solution for demanding presentation environments.
